Our scanner range is divided into 4 product lines: Basic, Small, Medium & Large. Adaptable to any needs, but also modular and upgradeable.
Pick the one for you now, knowing it can grow and evolve with you.

Book a demo
Basic
Small
Icon of the small scanner, with a normal sized car inside.
Medium
Icon representing the medium sized scanner, with a SUV in.
Large
Icon of the large scanner, with a van inside.

Features

LEGEND
Symbol meaning included.
Included
Symbol meaning optional.
Optional
Symbol meaning not included.
Not Available
InstaScan
Basic
Small
Medium
Large
VEHICLE SCANNER
Scanner configuration
Drive-through scanner for hazard crossing with a height of 1.60 m
Vehicle scanner with a height of 2.00 m
Vehicle scanner with a height of 2.00 m with additional cameras. Also available as a modular extension
Vehicle scanner with a height of 3.00 m (2.00 m + 1.00 m extension) with additional cameras. Also available as a modular extension
Scanner equipment
Incl. cameras, computer, memory and cabling
Incl. cameras, 2x computers, memory and cabling
Incl. cameras, 2x computers, memory, UPS and cabling
Incl. cameras, 2x computers, memory, UPS and cabling
Vehicle types
CAR
CAR
CAR + SUV
CAR + SUV + LCV
Average damage detection
>90%
>90%
>90%
>90%
Detection size (scratches, dents)
>3mm
>3mm
>3mm
>3mm
Scanning time / passage speed
5 to 10 seconds
max. 8 km/h
5 to 10 seconds
max. 8 km/h
5 to 10 seconds
max. 8 km/h
5 to 10 seconds
max. 8 km/h
Requirements
clean vehicle, defoiled, not covered with stickers
clean vehicle, defoiled, not covered with stickers
clean vehicle, defoiled, not covered with stickers
clean vehicle, defoiled, not covered with stickers
Face pixelation
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Deflectometry with lighting
Symbol meaning optional.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Daily vehicle volume
up to 2,000 passages
up to 2,000 passages
up to 2,000 passages
up to 2,000 passages
Installation / set-up time
1 day
2 days
2 days
2 days
Plug & Play (nur Strom + LAN-Versorgung)
per Stecker
per Festanschluss
per Festanschluss
per Festanschluss
LTE / 5G Module (Ericsson Router - Dt. Telekom)
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Cloud-Storage and Processing
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Indoor / Outdoor  (-10° to +40° C)
Outdoor possible (housing), not in hot countries
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Fan
small
large
large
large
Air-conditioning unit
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Frost guard
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
AI damage detection (Tchek - pre-installed)
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Optional AI damage detections (Solera, Bdeo)
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Production of appraisals (condition report, residual value appraisal)
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
WebApp for photos of the interior (synchronised)
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
REST API for system integration
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Compatibility
Symbol meaning not included.
to all additional modules
to all additional modules
to all additional modules
Additional Modules
Insta Tyre Scanner (Beissbarth) - for profile depth measurement
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta Tyre Scanner Pro (Beissbarth) - with photogrammetry for profil depth measurement and readout of the tyre sidewall with 22 parameters
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta Underbody Scanner (SecuScan) - for underbody scans plus battery check of high-voltage vehicles
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta Drive-over ramp - for the integration of the Insta tyre scanner and Insta underfloor scanner
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta Beauty-Shots - supplementing the scanner with beauty shot cameras for direct vehicle and image transfer for remarketing
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta Feets - addition of the scanner for attachment to the floor via steel plate
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
Insta-Mobility-Kit - addition of the scanner for mobile transport incl. trolley, edge protection, drawbar, 5G router
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
SCANNER HOUSING
One housing for multiple expansion stages
Symbol meaning not included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Drive-through traffic lights
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Stable frame construction - welded square tube frame with weatherproof metal housing
Symbol meaning not included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Maintenance cover on the rear
Symbol meaning not included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Maintenance cover side and rear
Symbol meaning included.
Symbol meaning not included.
Symbol meaning not included.
Symbol meaning not included.
Powder-coated housing in 3 RAL colours (silver, space grey, black)
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Scanner dimensions
H: 1.60m, L: 0.80m, W: 0.40m
H: 2,00m, L: 1.80m, W: 0.65m
H: 2.00m, L: 1.80m, W: 0.65m
H: 3.00m, L: 1.80m, W: 0.65m
Drive-through width
3.80m (standard)
3.80m (standard)
3.80m (standard)
3.80m (standard)
CAMERAS & LIGHT
Cameras (6x/8x/10x/14x)
6 x (3 left/ 3 right)
8 x (4 left/ 4 right)
10 x (5 left/ 5 right)
14 x (7 left/ 7 right)
Beautyshot cameras (4x)
Symbol meaning not included.
Symbol meaning optional.
Symbol meaning optional.
Symbol meaning optional.
High-performance cameras - high-resolution, sensor-controlled, with customised lenses
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Solid camera mounts - withstand vibrations or temperature fluctuations
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Double light panels - at full height with integrated deflectometry
Symbol meaning optional.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Intelligente Fahrzeugerkennung über Sensorik
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
Symbol meaning included.
UPS - Uninterrupted power supply
Symbol meaning not included.
Symbol meaning not included.
Symbol meaning included.
Symbol meaning included.
LEGEND
Symbol meaning included.
Included
Symbol meaning optional.
Optional
Symbol meaning not included.
Not Available
